DIMENSIONAL GAGE SYSTEMS



STANDARD GAGES

OMNI GAGES

  • Center Distances
  • Chord Spacing
  • Concentricity
  • I.D. (Inside Diameter)
  • O.D. (Outside Diameter)
  • Length
  • Taper

Omni Gage Brochure.pdf

GROOVE GAGES

  • Checks the whole groove-Perfect for: Snap Rings, "O" Rings, Recessed Diameters & Threads.

  • Provided with Electronic or Standard indicators.

  • Checks sizes from 0.500" to 4.875" (Specials to 12" and beyond Quoted per application).

  • Self-centralizing

  • Interchangeable gage heads with "groove-matched" blade contacts.

  • Custom ground for any groove or bore size.

  • Rugged enough to withstand tough environments.

Groove Gages Brochure.pdf

SWEEP GAGES

These rugged production gages are available in stock units or can be designed and built directly to customer specifications.



Ideal For:

  • Concentricity
  • Squareness
  • Hole Location
  • Profile of Surfaces

Sweep Gages Brochure.pdf

FLUSH PIN GAGES/TRANSFER UNITS/INDICATOR HOUSINGS



Easily mounted on fixture gages, A. G. Davis - AA Gage transfer units are available in a variety of configurations for most applications. Indicator housings provide a sturdy guard for A. G. Davis - AA Gage indicating units and the indicator.



Flush Pin Gages, Indicator Gages, and Set Masters.pdf
